Camera & Recording

Status displays, recording control, media, frame rate, resolution, and connection widgets.

Recording​

Record Record​

Record toggle button with a live status indicator (Recording / Standby).

  • Config: button style (button with indicator, large button, or full widget).

Rec Lock Rec Lock​

Locks record for the assigned camera. Acts as a toggle.

Recording formats​

Shows current recording format.

Status widgets​

Timecode Timecode​

Displays the current timecode as HH:MM:SS:FF.

  • Config: show/hide camera letter, show/hide recording indicator.

Clip Name Clip Name​

Shows the current clip filename being recorded, or the last recorded filename.

Camera Letter Camera Letter​

Shows the camera identifier letter (A, B, AA, …) as assigned by the camera or overridden by the user.

Lock (widget) Lock​

Performs the same function as the lock icon in the tab bar (locks the page), but can be placed anywhere on the grid.

Connection & networking​

Connection Connection​

Visual indicator of the camera's connection state.

  • States: green (connected), orange with pulse (connecting/reconnecting), red (disconnected/failed).
  • Config: show/hide camera letter, latency (ms), connection status, camera name.

Web GUI Web GUI​

Opens the camera's built-in web interface in a browser, skipping the login screen.

Reconnect Reconnect​

Drops and re-establishes the connection to the assigned camera with a single tap. Manual reconnection always works, even when Auto-connect is disabled for that camera in Settings → Cameras — useful when you'd rather control exactly when the app reaches out to a camera (see the Sony Venice connection notes for an example).

Reconnect All Reconnect All​

Reconnects every configured camera at once. Unlike most widgets, it isn't tied to a camera assignment.

Media Info Media Info​

Displays available media slots and remaining recording time. Supports a dual-slot configuration showing two slots at once, with a configurable low-media warning.

Using the example of a Sony Venice:

  • Slots: SxS A, SxS B, AXS A, AXS B.
  • Config: slot 1 selection; slot 2 enable/disable + selection; low-media warning threshold (off, 1, 2, 5, 10, 15, or 30 minutes).
Platform-specific

Available media slot types and configurations depend on the camera. See Supported Cameras.

Frame Rate (FPS) Frame Rate​

Shows the current frame rate, including variable frame rate when applicable.

  • Config: show/hide variable frame rate toggle; require confirmation before switching variable frame rate (off by default), show project base FPS (example: 24/24, 25/25, 60/24, and so on.)

Resolution Resolution​

Displays the current video resolution. Tapping it opens the camera's resolution and recording settings.

  • Config: show/hide pixel dimensions.
